1.
|
Effective Mould Area (mm) |
450L x 450W |
|
2.
|
Maximum Mould/
Block Height (mm)
|
200mm |
|
3.
|
Electrical Power 3Ph 440 Volt |
10.50 HP |
|
4.
|
Vibrator No(s) HP./Frequency |
2/2+1/3000 |
|
5.
|
No. of Hydraulic Cylinders |
5 |
|
6.
|
No. of Bricks/stroke (230x110x75) or Block (400x200x150/200) |
8/2 |
|
7.
|
Cycles/Minute |
2-3 |
|
8.
|
Production Capacity of
Bricks/ shift (Blocks
400x200x150/200)
|
6000 - 7000
(1000 - 1200)
|
|
9.
|
Product Mix. in Concrete
or Fly Ash/FAL G
|
Bricks Hollow/Solid
Blocks, Interlocking
Paver
|
|
10.
|
Feeding of Raw Materials |
Push Feed Manually |
|
11.
|
Placing of Pellets |
Individual by hand |
|
12.
|
Removal of Loaded Pallets |
By Hydraulic Jack |
|
13.
|
Vibro Hydraulic Flow
Combined Pressure (Appx.)
|
40 MT. |
|
14.
|
Type of Raw Material
could be utilised
|
Fly Ash + Lime +
Cement + Concrete
|
|
15.
|
Weight (Approx.) without
Accessories
|
2200 Kgs. |
| * All specifications are subject to change. |
