| 1. |
Effective Mould Area (mm) |
500x500 |
| 2. |
Maximum Brick Height (mm) |
100 |
| 3. |
Electric Power 3 Ph 440 Volt, 50 Hz. |
16H.P.+18 H.P. for (other equipments) |
| 4. |
Opreative Pressure |
+80 Tonnes |
| 5. |
No. of Hydraulic Cylinders |
07 (Seven) |
| 6. |
No. of Bricks/Strock (230x110x75) (190x90x90) |
8/10 |
| 7. |
Production Capacity of Bricks/Shift |
10000-14000 |
| 8. |
Product Cycle (Strocks) |
1.5 to 2.5/mint |
| 9. |
Feeding of Raw Materials |
Hydraulic Feeder |
| 10. |
Placing of Pallets |
Hydraulic Auto Palleting |
| 11. |
Removal of Loaded Pallets |
Hydraulic on Unloading Conveyor |
| 12. |
Hydraulic Oil |
400 Lits Grade 68 |
| 13. |
Weight (Appx.) |
5000 Kgs. |
| 14. |
Raw Material could be utilized |
Flyash, Lime, Cement, Concrete, Gypsum, Sand, Stone,
Dust etc. |
|
* Change
in specification at our will + Condition Apply.
|
