| 1. |
Effective Mould Area (mm) |
500L x 750W |
| 2. |
Maximum Mould/
Block Height (mm) |
200mm |
| 3. |
Electrical Power 3Ph 440 Volt |
12 HP |
| 4. |
Vibrator No(s) HP./Frequency |
2 HP/3000 |
| 5. |
No. of Hydraulic Cylinders |
6 |
| 6. |
No. of Bricks/stroke (230x110x75) or Blocks 4(400x200x200)
|
10/12 or 3 |
| 7. |
Cycles/Time |
20-30 Set (appx.) |
| 8. |
Production Capacity (Standard
Bricks Per shift) |
15000 - 20000 Bricks (appx.) |
| 9. |
Product Mix. in Concrete
or Fly Ash/FAL G |
Bricks Hollow/Solid Blocks, Interlocking Paver |
| 10. |
Feeding of Raw Materials |
Hydraulic Feeding with agitator |
| 11. |
Placing of Pellets |
Auto Placing |
| 12. |
Removal of Loaded Pallets |
By attachment of Front Fend Conveyor |
| 13. |
Unloading of Pallets |
By Stacker |
| 14. |
Type of Raw Material
could be utilised |
Fly Ash + Lime + Cement + Concrete + Sand +Gypsum + Concrete
|
| 15. |
Weight (Approx.) without
Accessories |
2000 Kgs. |
| 16. |
Pallets Size (both side film coated Highly Compressed B.W.P )
|
18mm thick 600 x 800mm |
|
* All
specifications are subject to change.
|
